Pink corundum powder F800 F1000

Pink corundum powder F800 F1000 is a extra fine pink corundum powder with chrominum oxide content. It is get from acid washing and suspension treatment process. After adding chromium material for electric melting, the fused corundum turns pink, and the micro powder produced is light pink.

$3,500.00$3,600.00 / MT

Pink corundum powder F800 F1000

Description:

Pink corundum powder F800 F1000 is a extra fine pink corundum powder with chrominum oxide content. It is get from acid washing and suspension treatment process. After adding chromium material for electric melting, the fused corundum turns pink, and the micro powder produced is light pink.

Pink corundum powder has the following advantages: high purity of alumina, higher toughness than white corundum, multiple sharp edges in the crystal, good durability, high hardness, strong impact resistance, and no iron element. The application covers in grinding tools, grinding paste, polishing, surface treatment, direct grinding and other fields.



Characteristic:

  1. The crystal has strong impact resistance, and the abrasive products produced are not easily deformed, with good shape retention
  2. The single particle strength of chrome corundum is 15-20% higher than that of white corundum, and its toughness is strong.
  3. Strong grinding ability and high efficiency.



Chemical composition:

AL2O3≥97.5%
Cr2O30.8-2.0%
NA2O≤0.55%
SiO2≤0.1%
Fe2O3≤0.1%



Physical properties:

Basic minerals:α-Al2O3
Crystal Size:600-800 μm
Hardness:Mohs:9
Knoop hardness:2200-2300 kg/cm3
Melting Point:2050 ℃
Specific Gravity:3.9-4.1g/cm3
Bulk density(LPD):1.40-1.91 g/cm3
Color:Pink
Particle shape:Angular



Applications

  1. Grind the grinding wheel.
  2. Grinding stones, triangular, circular, and columnar polishing grinding blocks.
  3. Honing advantages.
  4. Ceramic grinding wheel.
  5. Magnesite polishing block.
  6. Rubber bonded grinding wheel.
  7. Direct grinding and polishing.
  8. Polishing sand blocks and grinding wheels.



Available specifications:

JIS Grit SizeD0 size(um)D3 size (um)D50 size (um)D94 size (um)
240#≤ 127≤ 10357.0±3.0≥ 40
280#≤ 112≤ 8748.0±3.0≥ 33
320#≤ 98≤ 7440.0±2.5≥ 27
360#≤ 86≤ 6635.0±2.0≥ 23
400#≤ 75≤ 5830.0±2.0≥ 20
500#≤ 63≤ 5025.0±2.0≥ 16
600#≤ 53≤ 4120.0±1.5≥ 13
700#≤ 45≤ 3717.0±1.5≥ 11
800#≤ 38≤ 3114.0±1.0≥ 9.0
1000#≤ 32≤ 2711.5.±1.0≥ 7.0
1200#≤ 27≤ 239.5±0.8≥ 5.5
1500#≤ 23≤ 208.0±0.6≥ 4.5
2000#≤ 19≤ 176.7±0.6≥ 4.0
2500#≤ 16≤ 145.5±0.5≥ 3.0
3000#≤ 13≤ 114.0±0.5≥ 2.0
4000#≤ 11≤ 8.03.0±0.4≥ 1.8
6000#≤ 8.0≤ 5.02.0±0.4≥ 0.8
8000#≤ 6.0≤ 3.51.2±0.3≥ 0.6
